User’s Manual of FGSD-1022 Series
11
1.4 Product Features
¾ Physical Port
FGSD-1022
8-Port 10/100Base-TX RJ-45 interfaces
2 10/100/1000T TP combo interfaces
2 mini-GBIC/SFP slots, shared with Port-9 and Port-10
Reset button for system management
1 RS-232 male DB9 console interface for Switch basic management and setup
FGSD-1022P
8-Port 10/100Base-TX RJ-45 with PoE Injector
2 10/100/1000T TP combo interfaces
2 mini-GBIC/SFP slots, shared with Port-9 and Port-10
Reset button for system management
1 RS-232 male DB9 console interface for Switch basic management and setup
¾ Layer 2 Features
Prevents packet loss Flow Control:
• IEEE 802.3x PAUSE frame Flow Control for Full-Duplex mode
• Back-Pressure Flow Control in Half-Duplex mode
High performance Store and Forward architecture, broadcast storm control, runt/CRC filtering eliminates
erroneous packets to optimize the network bandwidth
8K MAC Address Table, automatic source address learning and ageing
Support VLAN:
• IEEE 802.1Q Tag-Based VLAN
• Port-Based VLAN
• Q-in-Q tunneling (Double Tag VLAN)
• GVRP for dynamic VLAN Management
• Private VLAN Edge (PVE / Protect Port )
Supports Link Aggregation
• Up to 13 Trunk groups
• Up to 8 ports per trunk group with 1.6Gbps bandwidth (Full Duplex mode)
• IEEE 802.3ad LACP (Link Aggregation Control Protocol)
• Cisco ether-Channel (Static Trunk)
Support Spanning Tree Protocol:
• STP, IEEE 802.1D (Classic Spanning Tree Protocol)
• MSTP, IEEE 802.1s (Multiple Spanning Tree Protocol, spanning tree by VLAN)
¾ Quality of Service
4 priority queues on all switch ports
Traffic classification:
• IEEE 802.1p Class of Service
• IP TOS / DSCP code priority
• Port Base priority
Strict priority and weighted round robin (WRR) CoS policies
