Planet FGSD-1022 [99/197] Mac filtering

User’s Manual of FGSD-1022 Series

4.7.3 MAC Filtering

By filtering MAC address, the switch can easily filter the pre-configured MAC address and reduce the un-safety. You can

add and delete filtering MAC address.

Figure 4-7-3: MAC Filtering interface

The page includes the following fields:

Object Description

MAC Address:

Enter the MAC address that you want to filter.

VLAN ID:

The VLAN ID for the entry.
