User’s Manual of FGSD-1022 Series
15
PoE Power Budget
- 180 Watts
Max. number of Class2 PD
8
Max. number of Class 3 PD
- 8
Standards Conformance
Safety
FCC Part 15 Class A, CE
Standards Compliance
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX/100BASE-FX
IEEE 802.3z Gigabit SX/LX
IEEE 802.3ab Gigabit 1000Base-T
IEEE 802.3x Flow Control and Back pressure
IEEE 802.1D Spanning tree protocol
IEEE 802.1w Rapid spanning tree protocol
IEEE 802.1p Class of service
IEEE 802.1Q VLAN Tagging
IEEE 802.1x Port Authentication Network Control
IEEE 802.3af Power over Ethernet ( FGSD-1022P only)
RFC 768 UDP
RFC 793 TFTP
RFC 791 IP
RFC 792 ICMP
RFC 2068 HTTP
RFC 1112 IGMP version 1
RFC 2236 IGMP version 2
Cable-Fiber-optic cable
• 50 / 125µm or 62.5 / 125µm multi-mode fiber cable:
- 100Base-FX : up to 2km
- 1000Base-SX: up to 220 / 550m
• 9 / 125µm single-mode cable, provides long distance for :
- 100Base-FX: up to 10/40/60km (very on fiber transceiver or SFP module)
- 1000Base-LX / ZX: 10 / 15 / 20 / 30 / 40 / 50 / 60 / 70 / 120km (very on fiber
transceiver or SFP module)
