User’s Manual of FGSD-1022 Series
184
6.18.4 Configure PoE -- Port
poe enable
Description:
Enabling or disabling the port POE injects function.
Command Level:
Global Configuration
Syntax:
poe enable [<port-list>]
[no] poe enable [<port-list>]
Parameters:
<port-list> specifies the ports to be set. If not entered, all ports are set.
Example:
Switch(config)# poe enable 1
Switch(config)# show poe status 1
Port Admin Oper Priority Power Limit[W]
Current
Consumption [W]
Current[mA]
Device
Class
Port1 Enable on High 15.4 13.4 279 0
Switch(config)# no poe enable 1
Switch(config)# show poe status 1
Port Admin Oper Priority Power Limit[W]
Current
Consumption [W]
Current[mA]
Device
Class
Port1
Disable
off High 15.4 -- -- 0
poe priority
Description:
Set port priority for the power supply management.
The command is configurable while “poe limit-mode” is set to “Port Priority”
Command Level:
Global Configuration
