User’s Manual of FGSD-1022 Series
Parameters:
<port-list> specifies the ports to be set. If not entered, all ports are set.
Example 1:
Switch(config)# show poe status 1
Port Admin Oper Priority Power Limit[W]
Current
Consumption [W]
Current[mA]
Device
Class
Port1 Enable on Low 15.4 13.4 279 0
Example 2:
Switch(config)# show poe status
Port Admin Oper Priority Power Limit[W]
Current
Consumption [W]
Current[mA]
Device
Class
Port1 Enable on Low 15.4 13.4 279 0
Port2 Enable on Low 15.4 11.3 236 0
Port3 Enable on Low 15.4 6.5 135 3
Port4 Enable off Low 15.4 0 0 0
Port5 Enable off Low 15.4 0 0 0
Port6 Enable off Low 15.4 0 0 0
Port7 Enable off Low 15.4 0 0 0
Port8 Enable off Low 15.4
0
0
0
6.18.2 Configure PoE Over Temperature Protection
poe temperature-protection enable
Description:
Configure PoE over temperature protection to enable or disable
Command Level
Global Configuration
Syntax:
poe temperature-protection { enable / disable }
Parameters:
<Enable > Enable PoE power budget change automatically by detected PoE unit temperature
<Disable > Disable PoE power budget change automatically
PoE temperature-protection working in Priority mode or Total Limit mode only.
182
