User’s Manual of FGSD-1022 Series

4.13 Power over Ethernet (FGSD-1022P)

Providing up to 8 PoE, in-line power interface, the FGSD-1022P PoE Switch can easily build a power central-controlled IP

phone system, IP Camera system, AP group for the enterprise. For instance, 8 camera / AP can be easily installed around

the corner in the company for surveillance demands or build a wireless roaming environment in the office. Without the

power-socket limitation, the PoE Switch makes the installation of cameras or WLAN AP more easily and efficiently.

4.13.1 Power over Ethernet Powered Device

3~5 watts

Voice over IP phones

Enterprise can install POE VoIP Phone, ATA and other

Ethernet/non-Ethernet end-devices to the central where UPS is installed

for un-interrupt power system and power control system.

6~12 watts

Wireless LAN Access Points

Museum, Sightseeing, Airport, Hotel, Campus, Factory, Warehouse

can install the Access Point any where with no hesitation

10~12 watts

IP Surveillance

Enterprise, Museum, Campus, Hospital, Bank, can install IP Camera

without limits of install location – no need electrician to install AC

sockets.

3~12 watts

PoE Splitter

PoE Splitter split the PoE 48V DC over the Ethernet cable into 5/12V DC

power output. It frees the device deployment from restrictions due to

power outlet locations, which eliminate the costs for additional AC wiring

and reduces the installation time.

125
