User’s Manual of FGSD-1022 Series
6.12 STP/MSTP Commands
[no] spanning-tree
Description:
Enable or disable spanning-tree.
spanning-tree forward-delay
Description:
Set spanning tree forward delay of CIST, in seconds.
Syntax:
spanning-tree forward-delay <4-30>
Parameters:
<4-30> specifies the forward delay, in seconds. Default value is 15.
The parameters must enforce the following relationships:
2*(hello-time + 1) <= maximum-age <= 2*(forward-delay - 1)
spanning-tree hello-time
Description:
Set spanning tree hello time of CIST, in seconds.
Syntax:
spanning-tree hello-time <1-10>
Parameters:
<1-10> specifies the hello time, in seconds. Default value is 2.
The parameters must enforce the following relationships:
2*(hello-time + 1) <= maximum-age <= 2*(forward-delay - 1)
spanning-tree maximum-age
Description:
Set spanning tree maximum age of CIST, in seconds.
Syntax:
spanning-tree maximum-age <6-40>
Parameters:
<6-40> specifies the maximum age, in seconds. Default value is 20.
162
