User’s Manual of FGSD-1022 Series

 Ingress/Egress Bandwidth control on each port

¾ Multicast

 IGMP Snooping v1 and v2

 IGMP Snooping v2 fast leave

 IGMP Query mode for Multicast Media application

¾ Security

 IEEE 802.1x Port-Based network access control protocol

 RADIUS users access authentication

 L3 / L4 Access Control List (ACL)

 Source IP-MAC / Port-Binding

 Port Security for Source MAC address entries filtering

¾ Management

 Switch Management Interface

- Telnet Command Line Interface

- Web switch management

- SNMP v1, v2c, v3 switch management

- SSL switch management

 DHCP client for IP address assignment

 DHCP Option82 and DHCP Relay

 Link Layer Discovery Protocol (LLDP) for easy network management

 Built-in Trivial File Transfer Protocol (TFTP) client

 Firmware upgrade via TFTP or HTTP

 Configuration restore / backup via TFTP or HTTP

 Event message logging to remote Syslog server

 Four RMON groups 1, 2, 3, 9 (history, statistics, alarms, and events)

 SNMP trap for interface Link Up and Link Down notification

 Supports Ping function

¾ Power over Ethernet (FGSD-1022P Only )

 Complies with IEEE 802.3af Power over Ethernet End-Span PSE

 Up to 8 IEEE 802.3af devices powered

 Support PoE Power up to 15.4 Watts for each PoE ports

 Auto detect powered device (PD)

 Circuit protection prevent power interference between ports

 Remote power feeding up to 100m

 PoE Management

• Total PoE power budget control

• Per port PoE function enable/disable

• PoE Port Power feeding priority

• Per PoE port power limit

• PD classification detection

• PoE Power Supply Over Temperature Protection
