User’s Manual of FGSD-1022 Series
127
The page includes the following fields:
Object Description
PoE PSU Status
PoE PSU Status shows status of power supply for PoE output.
PoE Temperature Unit 1
Display the current operating temperature of PoE chip unit 1.
The unit 1 is in charge of PoE Port-1~Port-4
PoE Temperature Unit 2
Display the current operating temperature of PoE chip unit 2.
The unit 1 is in charge of PoE Port-5~Port-8
Over Temperature Protection Enable / Disable over temperature protection.
When the PoE temperature unit 1 / unit2 over 70 degree C then PoE power
budget will be changed by 3 segments as following.
Over 70 Degree C power budget 180 Watts
Over 73 Degree C power budget 170 Watts
Over 76 Degree C power budget 160 Watts
Power limit mode Allow to configure power limit mode of Web Smart Device. It can choose :
Port Priority Deliver PoE power by port priority setting
Total Limit. Set limit value of the total POE port provided power to the
PDs.
Power Allocation Show the total watts usage of PoE Switch.
PoE Function Can enable or disable the PoE function.
Priority Set port priority for the POE power management
It can choose the “port priority”, value is :
Critical
High
Low
High priority is “Critical”.
Device class Class 0 is the default for PDs. However, to improve power management at the
PSE, the PD may opt to provide a signature for Class 1 to 3.
The PD is classified based on power. The classification of the PD is the
maximum power that the PD will draw across all input voltages and operational
modes. A PD shall return Class 0 to 3 in accordance with the maximum power
draw as specified by Table 4.1.
Current(mA) It shows the PoE device current Amp.
Consumption [W] It shows the PoE device current watt.
Power Limit It can limit the port PoE supply watts.
Per port maximum value must less than 15.4 watts, total ports values must
less than the Power Reservation value.
Once power overload detected, the port will auto shut down and keep on
detection mode until PD’s power consumption lower than the power limit value.
