3. Voltage Panel

Click the Voltage button in Main Panel, the button will be highlighted and the Voltage

Panel will slide out to up as the f ollowing figure.

In this panel, you can decide to increase CPU core voltage and Memory voltage or not.

The def ault setting is “No”. If y ou want to get the best performance of ov erclocking, we

rec om m end y ou clic k t he opt ion “Y es ”.
