Other Control SiE39-407
102 Function
• In order to set the SLAVE 2 to operation prohibition
mode, set No. 40 of Setting mode 2 to "SLAVE 2
OPERATION PROHIBITION".
(Procedure)
(1) Press and hold the PAGE button (BS1) for a period
of 5 seconds or more.
(2) Press the OPERATION button (BS2) 40 times.
(3) Press the CHECK button (BS3) once.
(4) Press the OPERATION button (BS2) once.
(5) Press the CHECK button (BS3) twice.
(6) Press the PAGE button (BS1) once.
∗
• In the case of multi-outdoor-unit system, “Inhibition of operation” is not set with each
compressor individually.
• In the case of multi-outdoor-unit system, when the above “Inhibition of operation” is set,
outdoor unit rotation is not functional.
5.3 Demand Operation
In order to save the power consumption, the capacity of outdoor unit is saved with control
forcibly by using “Demand 1 Setting” or “Demand 2 Setting”.
To operate the unit with this mode, additional setting of “Continuous Demand Setting” or
external input by external control adapter is required.
5.4 Heating Operation Prohibition
Heating operation is prohibited above 24°C ambient temperature.
(Factory set)
7
777777
777777
77
7
77
777
777
7
77777
77777
9
7
7777
7777
97
7
777777
777777
77
777
7777
7777
LED display (
7
:ON
7
:OFF
9
:Blink)
H1P
---
H7P
Note : Reset the power supply during the outdoor unit is stopping to cancel the
automatic backup operation forcibly.
Set item Condition Content
Demand 1 Mode 1 The compressor operates at approx. 60% or less of rating.
Mode 2 The compressor operates at approx. 70% or less of rating.
Mode 3 The compressor operates at approx. 80% or less of rating.
Demand 2 ⎯ The compressor operates at approx. 40% or less of rating.
