Field Setting SiE39-407
140 Test Operation
a. “Setting mode 1”
This mode is used to set and check the following items.
1. Set items ············ In order to make COOL/HEAT selection in a batch of outdoor unit group, change the setting.
• COOL/HEAT selection (individual) ············Used to select COOL or HEAT by individual outdoor
unit (factory set).
• COOL/HEAT selection (batch master)·······Used to select COOL or HEAT by outdoor unit group
with the master unit.
• COOL/HEAT selection (batch slave) ·········Used to select COOL or HEAT by outdoor unit group
with the slave unit.
2. Check items ·······The following items can be checked.
(1) Current operating conditions (Normal / Abnormal / In check operation)
(2) Setting conditions of COOL/HEAT selection (Individual / Batch master / Batch slave)
(3) Low noise operating conditions (In normal operation / In low noise operation)
(4) Demand operating conditions (In normal operation / In demand operation)
Procedure for changing COOL/HEAT selection setting
Press the OPERATION (BS2) button
to set the blinking of LED to any of
conditions shown on the right.
Press the CHECK (BS3) button to
determine the setting.
The system is normally set to "Setting
mode 1".
Should the system be set to any
mode other than that, press the
PAGE (BS1) button to set the system
to "Setting mode 1".
“Normally, “Setting mode 1” is set.
In case of other status, push MODE
button (BS1) one time and set to
“Setting mode 1”.
Check the system for each condition
through LED displays. (Refer to
information in table on the right.)
Pressing the CHECK (BS3) button
will bring the system to the initial
state of "Setting mode 1".
7
7
7
7
7
7
9
7
7
7
9
7
7
7
9
7
7
7
7
7
7
8 ON
7 OFF
9 Blinking
Procedure for checking check items
(V2763)
Page
H1P
Preparation
alarm
H2P
COOL/HEAT select
Individual
H3P
Batch master
H4P
Slave master
H5P
Low
noise
H6P
Demand
H7P
7787777
Setting (displaying) item
Page
H1P
Preparation
alarm
H2P
COOL/HEAT select
Individual
H3P
Batch master
H4P
Batch slave
H5P
Low
noise
H6P
Demand
H7P
For selection by individual outdoor unit (factory set)
For selection in a batch of outdoor unit group with master unit
For selection in a batch of outdoor unit group with slave unit
Pressing the CHECK (BS3) button will return the system to the initial condition of "Setting
mode 1".
Current operating conditions
7Normal 8Abnormal
9In preparation or in check
operation
Setting of COO/HEAT selection
877By individual outdoor
unit
787In a batch of outdoor unit
group with master unit
778In a batch of outdoor unit
group with slave unit
Low noise operating conditions
7In normal oper
ation
8In low noise operation
Demand operating conditions
7In normal operation
8In demand operation
