Wiring Diagrams for Reference SiE39-407
294 Appendix
FXLQ20M / 25M / 32M / 40M / 50M / 63MVE
FXNQ20M / 25M / 32M / 40M / 50M / 63MVE
3D039826A
A1P
C1R
F1U
HAP
K1R-K3R
M1F
Q1M
R1T
R2T•R3T
T1R
X1M
Printed circuit board
Capacitor (M1F)
Fuse (훾, 5A, 250V)
Light emitting diode
(Service monitor-green)
Magnetic relay (M1F)
Motor (Indoor fan)
Thermo switch
(M1F embedded)
Thermistor (Air)
Thermistor (Coil)
Transformer (220-240V/22V)
Terminal block (Power)
X2M
Y1E
R1T
SS1
X18A
Terminal block (Control)
Electronic expansion valve
Thermistor (Air)
Selector switch (Main/sub)
Connector (Wiring adaptor for
electorical appendices)
Indoor unit
Wired remote control
Connector for optional parts
POWER SUPPLY
220-240V
~
50Hz
220V
~
60Hz
Notes:
1. : Terminal block, , : Connector, : Terminal
2. : Field wiring
3. In case using central remote control, connect it to the unit in
accordance with the attached instruction manual.
4. When connecting the input wires from outside, forced off or on/off
control operation can be selected by remote control. In details, refer
to the installation manual attached the unit.
5. Symbols show as follows: PNK: pink, WHT: white, YLW: yellow,
ORG: or
ange, BLU: blue, BLK: black, RED: red, BRN: brown.
6. Use copper conductors only.
Note 4
Input from outside
Note 3
Transmission wiring
central remote control
Wired remote control
(Optional accessory)
Electric parts box
