SiE39-407 Wiring Diagrams for Reference
Appendix 287
FXKQ25M / 32M / 40M / 63MVE
3D039564A
A1P
A2P
C1R
F1U
HAP
K1R-K3R
KAR
KPR
M1F
M1P
M1S
Q1M
R1T
R2T•R3T
S1L
S1Q
T1R
X1M
X2M
Y1E
R1T
SS1
X16A
X18A
Printed circuit board
Terminal board
Capacitor (M1F)
Fuse (훾, 5A, 250V)
Light emitting diode
(Service monitor-green)
Magnetic relay (M1F)
Magnetic relay (M1S)
Magnetic relay (M1P)
Motor (Indoor fan)
Motor (Drain pump)
Motor (Swing flap)
Thermo switch
(M1F embedded)
Wired remote control
Connector for optional parts
Indoor unit
Thermistor (Air)
Thermistor (Coil)
Float switch
Limit switch (Swing flap)
Transformer (220-240V/22V)
T
erminal block (Power)
Terminal block (Control)
Electronic expansion
valve
Thermistor (Air)
Selector switch (Main/sub)
Connector (Adaptor for wiring)
Connector (Wiring adaptor
for electorical appendices)
POWER SUPPLY
220-240V
~
50Hz
220V
~
60Hz
Notes:
1. : Terminal block, , : Connector, : Terminal
2. : Field wiring.
3. In case using central remote control, connect it to the unit in accordance with the attached
instruction manual.
4. When connecting the input wires from outside, forced off or on/off control operation can be
selected by remote control.
In details, refer to the installation manual attached the unit.
5. In case high E.S.P. operation, change over the wiring connection from X2A tot X3A.
6. Symbols shows as follow
s: PNK: pink, WHT: white, YLW: yellow, ORG: orange, BLU: blue,
BLK: black, RED: red, BRN: brown, GRY: gray.
7. Use copper conductors only.
Note 4
Input from outside
Note 3
Transmission wiring
central remote control
Wired remote control
(Optional accessory)
Electric parts box
Note 5
