Planet IVS-H120 [10/91] Hardware installation

5V DC

The input power is 5V DC.

Note: ONLY use package power adapter supplied with the product.

Otherwise, the product may be damaged.

A/V Out

After connect with the A/V cable attached in packaging, it not only allows

this device to output audio or alerting sound, but also it provides composite

video output. User can use A/V cable to connect the video server with a TV

monitor or VCR.

Note:

1. The white jack is used for audio output, and yellow jack is used for video

output.

2. The IVS-H120 could determine the monitor use NTSC or PAL format

signal, and output the fitting video format to monitor automatically.

Please connect the video jack (yellow) with monitor properly before

power on the machine.

MIC in MIC-in (line level) jack allows any device that could input audio.

Reset

This button is used to restore the all factory default settings. Sometimes

restarting the device will make the system back to a normal state. However,

if the system still got problems after restart, user can restore the factory

default settings and install it again.

Restore the device:

a.) Press the button down continuously.

b.) Hold the button at least 5 seconds and release it. Then the

device has been restored to default settings and reboot again.

Note: Restoring the factory default setting will lose the all previous settings

included IP address forever. User needs to run the PLANET IPWizard II

program to search the device and configure it to let the device work properly

again.

2.3 Hardware Installation

2.3.1 Stand-alone Installation

To install an IVS-H120 stand-alone, on a desktop or shelf, simply complete the following steps:

1. Attach video source to IVS-H120

To use IVS-H120, user must supply video source to IVS-H120. Connect the BNC terminal of

camera to the IVS-H120’s video input and make sure to power on camera first.

2. Plug-in Ethernet cable into RJ-45 connector

Connect an Ethernet cable to the LAN socket located on the IVS-H120’s panel and attach it

to the network.
