Planet IVS-H120 [90/91] Appendix h product specification
![Planet IVS-H120 [90/91] Appendix h product specification](/views2/1071404/page90/bg5a.png)
90
Appendix H: Product Specification
Product
IVS-H120
Video Specification
Video Encoder H.264 / MPEG-4 / M-JPEG
Video Resolution D1, CIF, QCIF
Frame Rate 30fps for all resolution
Audio Specification
Audio Codec G.726 / AMR
Audio I/O Audio line in / out (for 2-way audio application)
Hardware Specification
Digit I/O DI x 1 / DO x 1
RS-485 For motor dome control
BNC Port 1 x BNC connector
Video Input 75 ohm impedance
Network and Configuration
Network Interface 1 x RJ-45, Ethernet 10Base-T/100Base-TX
Network Standard IEEE 802.3 / IEEE 802.3u
Network Protocol
TCP/IP, HTTP, SMTP, FTP, NTP, DNS, DDNS, DHCP, ARP,
Bonjour, UPnP, RTSP, RTP, PPPoE, 3GPP, ICMP, Samba
Browser / Software Microsoft ® Internet Explorer 6.0 or later, Cam Viewer Plus Lite/Pro
Motion Detection 10 area definable
Environment Specifications
Power Requirement 5V DC, 2A
Dimension (W x D x H) 94 x 70 x 26 mm
Weight 210g
Power Consumption 2.5W (Max.)
Operating Temperature 0 ~ 40 Degree C
Operating Humidity 20 ~ 80% (non-condensing)
Emission CE, FCC
