3.3 Live View
Start-up screen will be as follow no matter an ordinary users or an administrator.
A
ctiveX Control
Monitor Image Section: The image shot by the Video Server is shown here. The date
and time are displayed at the top of the window.
Video Profile: The Video Server support multi-profile for three compressions
H264, MEPG-4 and M-JPEG simultaneously. User can chose
the proper and/or preferred profile here.
Full Screen Click this button to display the image in full-screen mode (uses
every available space to display the image captured by this
camera).
2-Way Audio: The Video Server supports 2-way audio function. User can
chose to enable or disable this function by toggling the icon
below
: Disable audio uploading function.
: Enable audio uploading function.
Streaming Protocol
Language
Client Menu
Monitor Image Section
PTZ Control
Setting Menu
2-Wa
y
Audio
Video Profile
Video Information
Full Screen
31
