Tour Name: The group name of the sequence of camera tour. The maximum number of
camera tour is 16.
Running: Enable or disable this camera tour.
Preset: Set the sequence of the tour. Maximum 16 points can be assigned. The
selected preset position is added in the Sequence list from 1 to 16.
Wait Time: Type a period of time during which the camera is to stay at each preset point,
between 0 to 36000 seconds.
NOTE: To use the camera tour function, user must preset some camera positions
first. The maximum number of preset points is 64.
52
