18
In the PC terminal screen, type in the login user name and password to login the
system. Type the following CLI command to check current IP setting of all the
management ports.
enable
/*Go to enable command mode*/
show management
/*Display all system management port IP setting*/
WDS login: admin
Password:
VC-2402 IPDSLAM v0.05 (2008/05/09 16:29:59)
Hardware Version : D
CPLD Version : B3
CLI Module Version : 3.0.1.76
FWAPI Module Version : 1.0.4.9
SNMP Module Version : v4.6
SNTP Module Version : 1.0
OAMP Module Version : 3.0.1.76
VDSLMGR Module Version : 2.25
VDSLMGR_EMU Module Version : 2.1.0.18
WEB Module Version : 2.2-x
WDDI Module Version : 2.4.3.10
WLS Module Version : 3.2.3.10
localhost:>enable
localhost:%show management
GBE MGMT
---------------------------------------------------
MAC Address : 00:30:4f:71:36:71 00:30:4f:71:36:75
IP Address : 192.168.5.3 192.168.1.1
Network mask : 255.255.255.0 255.255.255.0
MTU : 1500 1500
MGMT default gateway : 192.168.1.254
Inband VLAN ID: No limit
Inband VLAN Priority: 0
localhost:%
Note
For both CLI and Web Configuration Tool, the default login user-
name and password are:
admin/admin.
Then type the following commands to change in-band or out-band IP settings as
you want:
congure
/*Enterconguremode*/
management gbe <ipv4 address> [netmask <netmask>]
/*Set in-band management port IP setting*/
management gbe vlan <vlan id> <priority>
/*Restrict incoming VLAN tag of in-band management; this setting is optional not
mandatory*/
