Planet VC-2402-48 [29/35] Button description
![Planet VC-2402-48 [29/35] Button description](/views2/1071634/page29/bg1d.png)
28
MGMT-Link/Act
(LED A on RJ-45)
Green - On
Off
Green - Blink
Valid Ethernet connection established
Disconnection
Transmitting or receiving data
SYS
Amber At power on phase
Red Self-test fail
Green Normal Operation
Green - Blink Remote download in operation
ALM
Off At power on phase
Red
Red – Blink
Major alarm set
Major and Minor alarm set
Amber Minor alarm set
Green Normal operation
DSL Status
Green - Scan
Green - On
Off
Green – Fast Blink
Green – Slow Blink
At power on phase
Port is activated, and linked
Disabled
Diagnostic, training
Hand-shaking
Interface Description
HK/ALM
RJ-50 port for housekeeping inputs and one alarm contact
output.
GBE1
Gigabit Ethernet trunk port 1 including an electrical (RJ-45)
and an optical (SFP) interface
GBE2
Gigabit Ethernet trunk port 2 including an electrical (RJ-45)
and an optical (SFP) interface
MGMT
Ethernet Port connected to LAN for providing system out-
band EMS/Telnet control interface, such as system monitor,
control or software upgrade.
CID
RS-232 port connected to the terminal for monitoring and
controlling the system.
POTS
RJ-21 connector (50-pin dual row header) for connecting
POTS lines.
LINE
RJ-21 connector (50-pin dual row header) for connecting
DSL lines.
Button Description
RST An embedded hardware button for hardware resetting.
ACO For Alarm Cut Off service.
