30
3. Troubleshooting the VC-2402
3.1 Introduction to Troubleshooting
This chapter describes instructions for the VC-2402 system problems. These
procedures may require the presence of technicians at remote VC-2402 system
sites and plus an operator at PC to monitor system alarms by console or EMS
during maintenance.
3.2 Resolving Problems Indicated Through LEDs
This section describes what to do to solve problems indicated by LEDs on the
system front panel.
Table 3-1
Problems Indicated by LEDs
LED Activity Problem Action
SYS
Not lit even
though DSLAM
is powered up
There is a power up
problem with the system.
Troubleshoot the DSLAM
for power up problems;
see section 3.4.
Red
Self-test failed. There is
a functional problem with
the system.
Replace the VC-2402.
ALM
Red Major alarm set See section 3.3.
Red-Flash Major and Minor alarm set See section 3.3.
Yellow Minor alarm set See section 3.3.
GBE1/GBE2
(If SFP
interface is
activated)
Not lit even
though DSLAM
is powered up
No link
Troubleshoot the
DSLAMforberoptics
problems; see section
3.4.
3.3 Resolving Problems Indicated Through Alarms
Alarms of the system are viewed through CLI commands or Web GUI.
If an alarm indicates a problem, refer to section 3.4 for troubleshooting procedures.
3.4 Procedures for Troubleshooting the VC-2402
When you follow a troubleshooting procedure, start from the rst step of the
procedure. If the rst step does not solvethe problem,proceed tothe next step;
keep going through the steps until the problem is solved. Use the following table to
ndouttheappropriateprocedurefortroubleshootingthelistedproblems.
