25
2. Operating and Maintaining the VC-2402
2.1 Maintenance requirement
2.1.1 Tools and Equipment Requirements
Lists required tools and test equipment for the VC-2402 system maintenance.
Required Installation Tools and Materials
Item Required Purpose
Anti-static wrist strap Protect the system from electrostatic discharge damage
Hand tool Screwdrivers for equipment removal and replacement
Wire cutter/stripper Prepare wires for electrical connections
Wire-wrap gun and
bit
Removing and replacing the system interconnection
wires
Wires System interconnections to external facilities
VF transmission and
signaling test sets
Testing faulty POTS
Fuse and alarm panel For protection and simplifying troubleshooting
2.1.2 System Spares
AlwayskeepsparesfortheDSLAMateachcentralofceforreplacementpurposes.
During the system trouble-shooting procedures, certain cards at the central ofce
and/or remote site will be required to be replaced.
2.1.3 Dispatching Maintenance Personnel
Some procedures in this manual involve end-to-end system testing, for which
technicians are needed at each remote site. The remote VC-2402 system sites are
normally unattended, however, technicians should be dispatched when needed. The
VC-2402 system maintenance efforts and monitor the system for alarms during
those on-site operations.
2.1.4 Electrostatic Discharge Protection
The VC-2402 system contains static-sensitive components. Be sure to wear a
properly grounded antistatic wrist strap when handling them. Also, when removing
and replacing a card, hold it either by its front ejector handle or by its edges.
Do not touch its rear connector contacts, which must remain free of contaminants.
2.1.5 Routine Maintenance
Always monitor the VC-2402 system performance at the central ofce / remote
sites using the SNMP. It allows user to view the current system status, alarm
information and to take the necessary corrective action if a problem is reported.
