1.4 CongurationImport/Export

The conguration database of VC-2402 contains two kinds of database - inband

database and general database. Inband database contains conguration for the

inband channel and is shared by two boot images (no matter which boot point you

choose,theinbandcongurationkeepsthesame).Generaldatabasecontainsother

conguration.

TheVC-2402 providestheconguration preservationfeaturethat the conguration

database is stored in ash memory (two partitions available). In addition to the

conguration preservation feature, the VC-2402 also provides the conguration

export/import feature.

ThefollowingparagraphdescribeshowtodothecongurationDBexport/importin

CLI and Web.

In CLI:

(A) Save runtime cong. and set to new active DB:

Ex:

enable

congure

runningcfg save [<inbandBackup Name>] [<generalBackup Name>]

/*BackupNameisoptional.WheninbandBackupNameisspecied,generalBackupName

isalsooptional.Ifomitted,usethesamenameas<inbandBackupName>*/

(B) Choose another DB / (C) Choose another DB and restart: (total 16 DB

for selection)

Ex:

enable

congure

runningcfg restore index <inbandBackupIndex> [<generalBackupIndex>][noreboot]

runningcfg restore name <inbandBackupName> [<generalBackupName>][noreboot]

/*You must add the word “noreboot” for action (B) so that the system will not reboot auto-

matically once the DB is changed*/

(D) Clear active DB including inband / (E) Clear active DB including inband

and restart:

Ex:

enable

congure

runningcfg clear all [noreboot]

/*You must add the word “noreboot” for action (D) so that the system will not reboot auto-

matically once the DB is cleared*/
