106
Chapter 9
Other Features and Settings
This Chapter explains the screens and settings available via the "Mis-
cellaneous" menu.
Overview
Normally, it is not necessary to use these screens, or change any settings. These
screens and settings are provided to deal with non-standard situations, or to provide
additional options for advanced users.
The screens available are:
PC Database
This is the list of PCs shown when you select the "DMZ PC",
"Virtual Server", or "Internet Application". This database is main-
tained automatically, but you can add and delete entries for PCs
which use a Fixed (Static) IP Address.
Remote
Administra-
tion
This feature allows you to manage VRT-401 via the Internet.
Routing
Only required if your LAN has other Routers or Gateways.
Firmware
Upgrade
The firmware (software) in VRT-401 can be upgraded using your
Web Browser.
UPNP
UPnP (Universal Plug and Play) allows automatic discovery and
configuration of VRT-401
9
