VRT-401 User Manual
116
For Router B's Default Route
Destination IP Address 0.0.0.0
Network Mask 0.0.0.0
Gateway IP Address 192.168.1.80 (VRT-401’s local router)
Firmware Upgrade
The firmware (software) in VRT-401 can be upgraded using your Web Browser.
You must first download the upgrade file, then select Upgrade on the Other menu. You
will see a screen like the following.
Figure 95: Upgrade Firmware Screen
To perform the Firmware Upgrade:
1. Click the "Browse" button and navigate to the location of the upgrade file.
2. Select the upgrade file. It's name will appear in the Upgrade File field.
3. Click the "Start Upgrade" button to commence the firmware upgrade.
VRT-401 is unavailable during the upgrade process,
and must restart when the upgrade is completed.
Any connections to or through VRT-401 will be lost.
