VRT-401 User Manual
12
PPTP Mainly used in Europe.
You connect to the ISP only
when required. The IP
address is usually allocated
automatically, but may be
Static (Fixed).
· PPTP Server IP Address.
· User name and pass-
word.
· IP Address allocated to
you, if Static (Fixed).
Other Modems (e.g. Broadband Wireless)
Type Details ISP Data required
Dynamic
IP Address
Your IP Address is allo-
cated automatically, when
you connect to you ISP.
Usually, none.
However, some ISP's may
require you to use a particu-
lar Hostname, Domain name,
or MAC (physical) address.
Static (Fixed)
IP Address
Your ISP allocates a per-
manent IP Address to you.
IP Address allocated to you,
mask and gateway (if pro-
vided), and DNS address.
Big Pond Cable (Australia)
For this connection method, the following data is required:
· User Name
· Password
· Big Pond Server IP address
SingTel RAS
For this connection method, the following data is required:
· User Name
· Password
· RAS Plan
