VRT-401 User Manual
2
Advanced Internet Functions
· Communication Applications. Support for Internet communication applica-
tions, such as interactive Games, Telephony, and Conferencing applications,
which are often difficult to use when behind a Firewall, is included.
· Special Internet Applications. Applications which use non-standard connec-
tions or port numbers are normally blocked by the Firewall. The ability to define
and allow such applications is provided, to enable such applications to be used
normally.
· Virtual Servers. This feature allows Internet users to access Internet servers on
your LAN. The required setup is quick and easy.
· DMZ. One (1) PC on your local LAN can be configured to allow unrestricted 2-
way communication with Servers or individual users on the Internet. This provides
the ability to run programs which are incompatible with Firewalls.
· URL Filter. Use the URL Filter to block access to undesirable Web sites by LAN
users.
· Internet Access Log. See which Internet connections have been made.
· VPN Pass through Support. PCs with VPN (Virtual Private Networking)
software using PPTP, L2TP and IPSec are transparently supported - no configura-
tion is required.
LAN Features
· 4-Port Switching Hub. VRT-401 incorporates a 4-port 10/100BaseT switch,
making it easy to create or extend your LAN.
· DHCP Server Support. Dynamic Host Configuration Protocol provides a
dynamic IP address to PCs and other devices upon request. VRT-401 can act as a
DHCP Server for devices on your local LAN and WLAN.
· Multi Segment LAN Support. LANs containing one or more segments are
supported, via VRT-401’s RIP (Routing Information Protocol) support and built-in
static routing table.
· DMZ Port. Used when allowing Servers on your LAN to be accessed from the
Internet, the DMZ port provides additional protection for both your Servers and
your LAN.
Configuration & Management
· Easy Setup. Use your WEB browser from anywhere on the LAN or WLAN for
configuration.
· Remote Management. VRT-401 can be managed from any PC on your LAN.
And, if the Internet connection exists, it can also (optionally) be configured via the
Internet.
· UPnP Support. UPnP (Universal Plug and Play) allows automatic discovery and
configuration of VRT-401. UPnP is by supported by Windows ME, XP, or later.
Security Features
· Password - protected Configuration. Optional password protection is
provided to prevent unauthorized users from modifying the configuration data and
settings.
· NAT Protection. An intrinsic side effect of NAT (Network Address Translation)
technology is that by allowing all LAN users to share a single IP address, the loca-
