VRT-401 User Manual
84
Pre-shared Key Xxxxxxxxxx Xxxxxxxxxx Must match
IKE Authentica-
tion algorithm
MD5 MD5 Must match
IKE Encryption DES DES Must match
IKE Exchange
mode
Main Mode Main Mode Must match
DH Group Group 1 (768
bit)
Group 1 (768
bit)
Must match
IKE SA Life time 28800 28800 Does not have to match.
Shorter period will be
used.
IKE PFS Disable Disable Must match
IPSec SA Parameters
IPSec SA Life
time
28800 28800 Does not have to match.
Shorter period will be
used.
IPSec PFS Disabled Disabled Must match
AH authentication
Disabled Disabled AH is rarely used
ESP authentica-
tion
Enable/MD5 Enable/MD5 Must match
ESP encryption Enable/DES Enable/DES Must match
