MH-2001 Multi-Homing Security Gateway User’s Manual
6.6.2 Script Blocking
To let Popup, ActiveX, Java, or Cookies in or keep them out.
Step 1. Click Content Blocking in the menu.
Step 2. Script Blocking detective functions.
Popup: Prevent pop-up boxes from appearing.
ActiveX: Prevent ActiveX packets.
Java: Prevent Java packets.
Cookie: Prevent Cookie packets.
Step 3. After selecting each function, click the OK button below.
Step 4. After finishing Script Blocking setting, you must enable it at Outgoing Policy, or Content Filtering
will not be workable.
The users may not use the specific function (like JAVA, cookie…etc.) to browse the website through this
policy. It can forbid the user browsing stock exchange website…etc.
- 94 -
