Ferroli SUN G10 2S [20/37] Operating instructions

ItalianoEnglishFrançaisDeutschEspañol

SUN G10 2S

Cod. 35445523 - 02/2007 (Rev. 00)

1. OPERATING INSTRUCTIONS

1.1 Introduction

Dear Customer,

Thank you for having chosen the SUN G10 2S, an advanced-concept FERROLI burner featuring cutting-

edge technology, high reliability and constructional quality.

The SUN G10 2S is an oil burner, whose compact dimensions and original design make it ideal for use

with most of the boilers currently present on the market. The attention paid to the design and industrial

production of the appliance has resulted in a product that is well-balanced and highly efficient, with very

low CO and NOx emissions and a very silent flame.

1.2 Operating instructions

The operation of the burner, once correctly installed and adjusted, is completely

automatic and does not require any intervention by the user. In the event of no fuel

or operating anomalies, the burner stops and shuts-down (the red light on the reset

button turns on). It is recommended to replete the supply of fuel before it runs out

completely, to avoid the inlet of air (irregular operation of the burner) or the loss of

prime of the pump (in which case the assistance of the service centre is required).

If the fuel tank is outside, in areas where the temperature falls below -10 °C, the

tank and fuel supply pipes must be adequately protected. Use winter oil or add a

specific anti-freeze.

Make sure that the room where the burner is installed is free of inflammable objects

or materials, corrosive gas or volatile substances, and is not dusty. Dust, in fact, is

sucked in by the fan and sticks to the blades of the rotor and reduces air flow, or

alternatively blocks the flame stability disk, compromising efficiency.

Do not allow the burner to be tampered with by inexpert persons or children.

1.3 Maintenance

Make sure that maintenance is performed on the burner periodically, at least once a year. The mainte-

nance operations must be performed by qualified and specialist personnel according to the indications

contained in chapter 3.

1.4 Anomalies

If the burner does not ignite and the red light on the reset button is not on, check that there is electri-

cal power, that the heating system switch is on, that the fuses are intact and that there is an effective

request for heat from the boiler.

If the burner is still off (red light on the reset button on), wait 15 seconds and press the reset button to

reset operation. The burner will attempt to ignite. If it shuts down again, check that there is fuel in the

tank and that the manual valves located on the oil supply pipe are open. If these checks do not resolve

the problem, contact the service centre.

If noise is produced during the operation of the burner, contact the service centre.

fig. 1

Burner

reset

button
