Chapter 3: Using AirOS™ on the AirRouter HP AirRouter
HP User Guide
Ubiquiti Networks, Inc.
Chapter 3: Using AirOS™ on
the AirRouter HP
AirOS™ is an advanced operating system that is capable of
powerful wireless and routing features. AirOS is built upon
a simple and intuitive user interface. AirOS allows you to
maximize the wireless performance of your AirRouter HP.
To access the interface, perform the following steps:
1. Launch your Web browser and type http://192.168.1.1
in the address field and press enter (PC) or return (Mac).
2. The login screen will appear. Enter ubnt in the
Username and Password fields and click Login.
Interface Tabs
The AirRouter HP interface contains six primary tabs. This
User Guide covers each tab with a chapter. For details on a
specific tab, refer to the appropriate chapter.
•
Main The Main tab displays AirRouter HP status
information and provides network monitoring links.
“Main Tab” on page 6.
• Wireless The Wireless tab allows you to configure
the wireless mode, the basic wireless settings and the
wireless security settings for the AirRouter HP. “Wireless
Tab” on page 11.
• Network The Network tab covers the configuration of
the network operating mode, IP settings, packet filtering
routines and network services. “Network Tab” on page
18.
•
Advanced The Advanced tab settings are available for
additional wireless interface controls. Advanced wireless
settings can be configured in this tab. The Advanced
tab also includes advanced Ethernet and traffic shaping
settings. “Advanced Tab” on page 35.
•
Services The Services tab covers the configuration
of system management services like Ping Watchdog,
SNMPAgent,WebServer,SSHServer,TelnetServer,
NTPClient,DynamicDNSandSystemLog.“Services
Tab” on page 38.
• System The System tab contains controls for system
maintenance routines, administrator account
management, device customization, firmware upgrade
and configuration backup. The AirMax feature can be
enabled and the interface language can also be selected
here. “System Tab” on page 41.
Each tab also contains network administration and
monitoring tools:
• “Align Antenna” on page 43
• “Site Survey” on page 44
• “Ping” on page 44
• “Traceroute” on page 44
• “Speed Test” on page 45
• “AirView” on page 45
