Troubleshooting> 138
4. Close the side cover.
O
PEN
COVER
,
PAPER
JAM
,
TOP
COVER
1. Squeeze the top cover handle (1) and open the top cover.
WARNING!
Be careful not to touch the fuser unit which is hot after
printing.
1
