Printer and paper overview> 29
P
APER
INPUT
AND
OUTPUT
INFORMATION
The following table relates paper parameters to input trays (Tray 1
to Tray 3 (numbering from the top) and MP Tray) and to output
areas (Face-down stacker and Face-up stacker).
a See important comments in “Paper recommendations” on page 28.
T
RAYS
AND
STACKERS
T
RAYS
1
TO
3
Tray 1 is the standard blank paper input tray and can hold up to 530
sheets of 75 g/m² paper. Additional trays, to give a total of three,
can be added as an option to give a total tray capacity of 1590 sheets
of 75 g/m² paper.
If you have identical paper stock loaded in another tray (for example
Tray 2 or the MP Tray), you can have the printer automatically
switch to that other tray when the current tray runs out of paper.
This function can be enabled by driver settings when printing from a
Windows application or by a menu setting when printing from other
applications.
TYPE SIZE WEIGHT INPUT/
OUTPUT
Plain paper A3, A3 Nobi, A3 Wide,
A4, A5, A6, B4, B5,
Letter, Legal 13,
Legal 13.5, Legal 14,
Executive, Tabloid,
Tabloid Extra
64 – 216 g/m² Any Tray
Any Stacker
217 – 300 g/m²
MP Tray
Face-up Stacker
Custom:
W: 100 – 328 mm
L: 148 – 457.2 mm
64 – 216 g/m² Any Tray
Face-up Stacker
Custom:
W: 79.2 – 328 mm
L: 90 – 457.2 mm
64 – 300 g/m² MP Tray
Face-up Stacker
Transparencies
a
A4, Letter 0.1 – 0.11 mm Tray 1 or MP Tray
Face-up Stacker
