Appendix B – Menu system> 155
S
YSTEM
ITEM VALUE DESCRIPTION
Serial Number xxxxxxxxxxxxxxx Displays serial no. of the
printer.
Asset Number xxxxxxx Displays Asset Number.
Asset Number is 8
alphanumeric characters
that can be assigned by
a user. Same as Asset
Number of Menu Map.
CU Version xx.xx Displays version no. of
CU (Control Unit)
firmware.
Same as CU version of
Menu Map.
PU Version xx.xx.xx Displays version no. of
PU (Print Unit) firmware.
Same as PU version of
Menu Map.
Total Memory xx MB Displays total RAM
memory installed in the
printer.
Same as Total Memory
of Menu Map.
Flash Memory xx MB [Fxx] Displays total flash
memory installed in the
printer and version.
Same as Flash Memory
of Menu Map.
HDD xx.xx GB [Fxx] Displays size of hard
disk and file system
version.
Same as HDD of Menu
Map.
