OKI C920WT [20/169] Opening and closing the top cover
![OKI C920WT [20/169] Opening and closing the top cover](/views2/1073999/page20/bg14.png)
Printer and paper overview> 20
P
RINTER
AND
PAPER
OVERVIEW
O
PENING
AND
CLOSING
THE
TOP
COVER
To open the top cover, squeeze the top cover handle (1) to release
the catch and raise the cover.
CAUTION!
To gain access to the inside of the printer, ensure that
the top cover is fully opened.
1
