Appendix B – Menu system> 159
Traym Config,
where m is in
range 1 to 3
(similar
arrangement
for all trays)
Paper Size Cassette Size
Custom
Sets paper in Traym.
X Dimension 3.9 – 8.3 (A) –
8.5 (L) – 12.9
inch
100 – 210 (A)
– 216 (L) –
328 mm
Sets Custom paper
width for Traym. Sets
for the direction
perpendicular to the
direction of paper
movement.
Y Dimension 5.8 – 11 (L) –
11.7 (A) – 18
inch
148 – 279 (L)
– 297 (A) –
457 mm
Sets Custom paper
length for Traym. Sets
for the same direction
as paper movement.
Media Type Plain
Letterhead
Transparency
Bond
Recycled
Card stock
Rough
Glossy
USERTYPE1
USERTYPE2
Sets the media type for
Traym.
USERTYPE1 and
USERTYPE2 are
reserved for custom
paper sizes set in the
printer driver.
Media Weight Auto
Light
Medium Light
Medium
Medium Heavy
Heavy
Ultra Heavy 1
Ultra Heavy 2
Ultra Heavy 3
Sets media weight for
Traym.
A3 Nobi
Paper
A3 Nobi
A3 Wide
Tabloid Extra
The printer detects A3
Nobi, A3 Wide and
Tabloid Extra sizes as
the same. Use this
setting to tell the
printer which of the
three sizes is loaded in
Traym.
Traym Config,
where m is in
range 1 to 3
(similar
arrangement
for all trays)
Legal 14
Paper
Legal 14
Legal 13.5
Sets the length of the
legal paper in Traym.
Change this to Legal
13.5 if that is the
standard legal size in
your country.
ITEM VALUE DESCRIPTION
