Consumables and maintenance> 101
NOTE
Open the top cover fully while replacement. Otherwise the printer
may be damaged.
3. Take out four image drums, and put them on a flat surface.
NOTE
- Do not lift the drum basket (2).
- Do not pull the blue lock lever of the toner cartridge when
removing the image drum cartridge.
CAUTION!
The green image drum surface at the base of each
cartridge is very delicate and light sensitive. Do not
touch it and do not expose it to normal room light for
more than 5 minutes. If the drum unit needs to be out of
the printer for longer than this, please wrap the
cartridge inside a black plastic bag to keep it away from
light. Never expose the drum to direct sunlight or very
bright room lighting.
