Appendix B – Menu system> 153
C
ONFIGURATION
P
RINT
P
AGE
C
OUNT
S
UPPLIES
L
IFE
ITEM VALUE DESCRIPTION
Traym nnnnnn Displays total printed
pages from Traym,
where m is in range 1 to
3.
MP Tray nnnnnn Displays total printed
pages from MP tray.
ITEM VALUE DESCRIPTION
xxxx Drum Remaining nnn% Displays the remaining
life span of the xxxx
drum as a percentage
where xxxx can be
Cyan, Magenta, Yellow,
White.
Belt Remaining nnn% Displays the remaining
life span of the belt unit
as a percentage.
Fuser Remaining nnn% Displays the remaining
life span of the fuser
unit as a percentage.
xxxx Toner
(n.nK)
Remaining nnn% Displays the remaining
life span of xxxx toner
as a percentage, where
xxxx can be Cyan,
Magenta, Yellow, White.
(n.nK) indicates the
capacity of the toner
cartridge being used.
