3
6
MENU
Push [BRILL] to turn the [BRILL] menu ON or OFF.
■BRILL. (Brilliance)
• Push [ ]/[ ] to select [BRILL.], then push [ ]/[ ] to
change the setting.
■CONTR. (Contrast)
• Push [ ]/[ ] to select [CONTR.], then push [ ]/[ ] to
change the setting.
■DISP. (Display type)
• Push [ ]/[ ] to select [DISP.], then push [ ]/[ ] to se-
lect the “Positive display” or “Negative display”.
NOTE:
Pushing and holding [BRILL] for 1 sec, returns the brilliance
and contrast setting to the default setting.
BRILL. CONTR. DISP.
POSI
NEGA
■ BRILL MENU ■ ADJ(Adjust menu)
TUNE GAIN SEA RAIN IR ES PULSE
ON
ON LP
OFF
OFF SP
A
U
T
O
A
U
T
O
Push [ADJ] to turn the ADJ. menu ON or OFF.
• Push [ ]/[ ] to select the item and push [UP] or [DOWN]
to change the setting.
[TUNE], [GAIN], [SEA] control
•While selecting each item, push and hold [ADJ] for
0.5 sec. to turn the “AUTO function” ON and OFF.
■TUNE
•
“AUTO.TUNE” appears for approx. 5 sec. instead of the
screen display, when first transmitting after turning the
power on. The unit also re-tunes in some cases.
•When activating the manual tuning slider, push [ ]/[
]
to adjust desired tuning level.
■ GAIN CONTROL [GAIN] (p. 11)
Adjusts the receiver amplifier gain.
•Increased gain may increase screen noise.
■SEA CLUTTER CONTROL [SEA] (p. 12)
• This function serves to eliminate echoes from the
waves at close range.
•Reduces the receiver gain for close objects within a
radius of 8 miles to eliminate sea clutter.
•Under normal conditions set the SEA to a minimum or
AUTO.
•Use this control with caution when the sea is rough.
■RAIN CLUTTER CONTROL [RAIN] (p. 12)
This function eliminates reflection echoes from rain,
snow, fog, etc.
■IR (p. 13)
•OFF : Turn the Interference Reduction function OFF.
•ON : Turn the Interference Reduction function ON.
■ECHO STRETCH [ES] (p. 13)
•OFF : Turn the echo stretch function OFF.
•ON : Turn the echo stretch function ON.
■PULSE
•LP:Select the long pulse. LP indicator appears on the
screen.
•SP:Select the short pulse.
