![Icom MR-570R [15/49] I int setting](/views2/1074308/page15/bgf.png)
9
3
MENU
Push [MENU] several times to turn the EPA menu ON.
• Push [ ] to select the [INT.SETTING] and push [ ] to
open the [INT.SETTING] menu.
■BEEP
•OFF :Turn the beep tone OFF*.
•ON :Turn the beep tone ON.
* Except alarm function.
■DIST UNIT
•NM :Display the distance unit as NM.
•KM :Display the distance unit as KM.
■BRG
Select the displayed bearing type, no relation with the
bearing data format (NMEA, N+1 or AUX).
•TRUE :Select the true bearing.
•MAG :Select the magnetic bearing.
■MAG VAR
•AUTO* :Revise magnetic variation automatically.
*NOTE: NMEA data is required. NEVER select
“AUTO” without NMEA data, incorrect variation
data may entered. (p. 38)
•MANUAL :Revise magnetic variation manually.
•Push [ ]
to select [MANUAL],then push
[ ]
. Set the revised value with
[ ]/[ ]
.
Push
[ ]
or [MENU] key to abort the
menu.
■BRG INPUT
•NMEA :NMEA0183 bearing data format.
•N+1 :N+1 data format.
•AUX :Other format.
■SPD INPUT
•GPS :Use the GPS NMEA speed data.
•LOG :Use the speed sensor data.
■TX INH START
•0 to 359° :Push [ ]/[ ] key to enter the start point
of the TX inhibit area.
■TX INH ANGLE
•0 to 90° :Push
[ ]/[ ] key to enter the TX inhibit
area.
■ SERVICE MAN
•Push [ ] to open the SERVICE MAN menu.
NOTE: This menu exists for service or maintenance
purposes only.
BEEP
DIST UNIT
BRG
MAG VER
BRG INPUT
SPD INPUT
TX INH START
TX INH ANGLE
SERVICE MAN
INT.SETTING
OFF ON
NM KM WI
TRUE MAG
AUTO MANU.
!! 0.0 E
NMEA
N+1 AUX
GPS LOGOF
0
0
■ INT. SETTING
