8
3
MENU
Push [MENU] several times to turn the [EPA] menu ON
or OFF.
• Push [ ]/[ ] to select the item and push [ ]/[ ] to
change the setting.
■EPA
•OFF :Turn the EPA function OFF.
•ON :Turn the EPA function ON.
■VECT
•TRUE :Select the true vector mode.
•REL :Select the relative vector mode.
■No.DISP
•OFF :For not displaying any mark number.
•Sel :Display the selected mark number only.
•ALL :Display all mark numbers.
■ALARM (CPA/TCPA)
•OFF :Turn the alarm function OFF.
•ON :Turn the alarm function ON.
■CPA* LIMIT
•0.1 to 50.0 NM:Set the CPA (Closest Point of Ap-
proach) limit with [ ]/[ ]keys.
■TCPA* LIMIT
•1 to 60 MIN. :Set the TCPA (Time to CPA) limit time
with [ ]/[ ] keys.
*CPA/TCPA: Closest Point of Approach and Time to Clos-
est Point of Approach limit is defined by the observer to
give a warning when a target or targets are close to
within those limits from your own ship.
■ INT. SETTING
•Push [ ] to open the INT. SETTING menu. (see
right)
EPA
VECT
No.DISP
ALARM
CPA LIMIT
TCPA LIMIT
INT.SETTING
EPA MENU
OFF ON
TRUE REL
OFF SEL ALL
OFF ON
1.0NM
10MIN
■ EPA(Electronic Plotting Aid)
*NOTE: External data is required for screen display infor-
mation. (p.38).
