Icom MR-570R [44/49] External data list
![Icom MR-570R [44/49] External data list](/views2/1074308/page44/bg2c.png)
38
14
EXTERNAL DATA LIST
EXTERNAL DATA INPUT
NMEA1*
2
NMEA2*
2
“HDT”, “HDM”“RMC”, “GGA”, “GLL”, “VTG”, “WPL”, “BWC”, LOG
N+1, AUX
FUNCTION DISPLAY BEARING SPEED POSITION WAY POINT
HEAD UP HU
COURSE UP CU Required
NORTH UP NU Required
TRUE MOTION OG*
1
TM Required “RMC”, “GGA” or “GLL”
TW*
1
TM Required LOG
SPEED DISPLAY OG*
1
SOG “RMC” or “VTG”
TW*
1
STW LOG
HEADING BEARING HDG Required
WAY POINT WPT Required “RMC”, “GGA” or “GLL”“WPL” or “BWC”
OWN VECTOR OG*
1
Required “RMC” or “VTG”
TW*
1
Required LOG
MOB MOB Required “RMC”, “GGA” or “GLL”
EPA OG*
1
EPA Required “RMC” or “VTG”
TW*
1
EPA Required LOG
VRM/PI/WPT/MOB estimated time OG*
1
“RMC” or “VTG”
of arrival TW*
1
LOG
MAGNETIC VARIATION (AUTO) “RMC” or “VTG”
*
1
OG; Over ground, TW; Through the water.
*
2
NMEA1 and NMEA2 connectors; See p. 26.
•“HDT”, “HDM”, “RMC”, “GGA”, “GLL”, “VTG”, “WPL” and “BWC” are SENTENCES of the NMEA0183.
The following external bearing, speed, position and
way point data is (are) required , when you use the
radar functions.
