Icom MR-570R [37/49] Service man menu
![Icom MR-570R [37/49] Service man menu](/views2/1074308/page37/bg25.png)
31
10
SERVICE MAN MENU
To open the “SERVICE MAN” menu.
q Push [MENU] several times to show the “EPA”
menu.
w Push [ ] to select “INT. SETTING”, then push
[ ]
to show the “INT. SETTING” menu.
e Push
[ ]
to select “SERVICE MAN”, then push
[ ]
to open the “SERVICE MAN” menu.
■SPD ADJ.
•Enter the pulse rate of the speed sensor.
■HDG ADJ.
•Adjusts the electronic heading line adjustment.
■TIMING ADJ.
•Corrects the distance.
■MBS SET
•Adjusts the MBS.
■TUNE PRESET
•Pre-adjust the objects for clarity on the screen above
the 6 NM range.
■TUNE SET
•Adjusts the object more clearly.
■T.METER SET
•Adjusts the tuning level indication to the max. level.
■RANGE
•
1
/8,
1
/4,
1
/2,
3
/4, 1, 1.5, 2, 3, 4, 6, 8, 12, 16, 24, 32, 36
: Choose the selectable screen range.
■Other readouts
•OUTPUT VOLTAGE: Shows the voltage level for the
scanner unit from the display
unit.
•HV (High voltage): Shows the voltage level in the
high-voltage unit in the scanner
unit.
•MONITOR: Shows the voltage level for checking the
receiver unit operation.
•HEATER:Shows the heater current.
•MG:Shows the current level for the Magnetron.
•TX TIME:Shows the total transmitted time.
SPD ADJ.
HDG ADJ.
TIMING ADJ.
MBS SET
TUNE PRESET
TUNE SET
T.METER SET
ENGLISH
24000
0.0
OUTPUT VOLT. 30.2
HV 349
MONITOR 47
HEATER 0.53
MG 0.0
TX TIME
1.2H
1/2
1/4
1/8
3/4
2
3
1
1.5
4
6
36
8
12
16
24
32
36
■ Service man menu
CAUTION: The SERVICE MAN MENU is
available for service purposes only. DO NOT
change any setting on the menu, otherwise the
equipment may not operate at it’s original per-
formance.
