15 MODE SELECTIVE SCAN SWITCH When this switch is pushed only memory channels stored with the operating mode which is displayed on the fre quency display just prior to pushing this switch are selected by turning the tuning control or scanning 22 INCREMENTAL TUNING CONTROL Shifts the receive frequency 9 9KHz maximum to either side of the transmit frequency when the RIT is ON and shifts the transmit frequency to either side of the receive frequency when the XIT is ON 16 SCAN START STOP BUTTON Starts and stops any of the scan functions When depress ing it again to restart the scan it will start from the stopped frequency in the programmed scan or from the highest memory channel in the other memory scans Rotating this control clockwise side raises the receive or transmit frequency and counterclockwise side lowers the frequency with 10Hz steps and 1KHz and 100Hz digits of the frequency shifted are displayed on the fre quency display 17 DIAL LOCK SWITCH After the IC 751 is set to a certain frequency for rag chew ing mobile operation etc by pushing this switch the VFO is electronically locked at the display frequency thus inactivating the operation of the tuning control To change frequency the dial lock must first be disengaged by pushing and releasing this switch again When both the RIT and XIT switches are ON the receive and transmit frequencies are the same and this frequency can be shifted either side from the displayed frequency by the control 23 RIT SWITCH Switches the RIT Receiver Incremental Tuning circuit ON and OFF 18 TUNING CONTROL Rotating this control clockwise increases the frequency or the memory channel number while rotating it counter clockwise decreases it The frequency changes by 10Hz in any mode In 10Hz step tuning rate by turning the tuning control faster the 50Hz step tuning rate is automatically selected This makes it very convenient to make a QSY over a wide frequency range To turn ON the RIT push this button once At this time the letters RIT and shifted frequency are displayed on the frequency display If you desire to turn OFF the RIT push the button again The letters RIT and shifted frequency are no longer displayed however the shifted frequency is stored in the memory and if you turn ON the RIT again the shifted frequency appears on the display again This control is also used to select the operating band while the BAND SELECT FUNCTION switch is depressed 24 XIT SWITCH Switches the XIT Transmitter Incremental Tuning circuit ON and OFF 19 TUNING RATE SWITCH By pushing in this switch the operating frequency is changed to correspond to 1 KHz increments in any mode At the same time the 100Hz digit on the display is cleared to show 0 When this switch is pushed again and released the frequency is changed normally This switch allows you to quickly QSY over a great frequency range 20 DIAL FUNCTION SELECT SWITCH In the VFO operation by pushing in this switch the operating frequency displayed VFO frequency is locked and the memory channel number displayed on the fre quency display can be changed by turning the tuning control To turn ON the XIT push this button once At this time the letters XIT and shifted frequency are displayed on the frequency display The other functions are in like manners 25 RIT XIT CLEAR BUTTON By pushing this button a frequency INCREMENTAL TUNING control rs When pushing the FUNCTION KEY the shifted frequency is added to the shifted frequency is cleared to 0 0 shifted by turning the cleared to 0 0 first then this button displayed one and the 26 FILTER SWITCH Selects the combination of the second IF 9MHz filter and the third IF 455KHz filter to improve the selectivity In the MEMORY CHANNEL mode by pushing in this switch the memory channel is locked and the operating frequency displayed frequency can be changed by turning the tuning control 27 NOTCH FILTER SWITCH Switches the notch filter function ON and OFF 21 BAND SELECT FUNCTION SWITCH By pushing in this switch the operating band is changed by turning t e TUNING CONTROL In the HAM BAND mode each initialized frequency of the band is selected In the GENERAL COVERAGE mode the operating frequency is changed in 1MHz steps but the lower digits do not change 28 P B TUNE PASS BAND TUNING CONTROL Allows continuous tuning of the pass band selectivity by moving the filter up to 800Hz from the upper or lower side in SSB CW and RTTY Not only improves selectivity but also can improve the audio tone Normal position is in the center 12 o clock position and is 2 3KHz wide in SSB 7
