29 NOTCH FILTER CONTROL Shifts the notch filter frequency Adjust the control so that the interference is reduced 30 COMP SPEECH PROCESSOR SWITCH Switches the speech processor circuit ON and OFF This circuit enables greater talk power and better results in DX operation 31 MONITOR SWITCH In the SSB transmit mode the transmitting IF signals can be monitored by turning this switch ON At this time use headphones or reduce receiver audio volume to prevent howling This switch also turns the CW side tone circuit ON and OFF in the CW mode 32 NB TIMING SWITCH The noise blanker blanking time can be selected NORMAL and WIDE by this switch It will be effective against any types of noises 33 VOX GAIN CONTROL When the control is turned completely counterclockwise the VOX circuit is OFF By turning the control clockwise beyond the click the VOX circuit is turned ON and the VOX gain increases by further rotating it clockwise When the VOX is turned ON in SSB AM or FM T R switching is accomplished by means of a voice signal In CW operation semi break in or full break in switching by means of keying possible 38 MODE SELECT SWITCHES Selects any one of four operating modes by simply pushing the desired switch Additionally these switches have dual functions as follows 1 AM For AM operation FM Pushing the FUNCTION KEY first then AM switch the FM mode is selected the 2 CW For normal CW operation NARROW Pushing the FUNCTION KEY first then the CW filter when the optional 455KHz narrow CW filter is installed No sound can be heard when the optional filter is not in stalled 3 SSB Upper sideband USB for 10MHz band and above and lower sideband LSB for 7MHz in the GENERAL COVERAGE operation 9MHz band and below normal SSB opera tion will be selected REVERSE Lower sideband LSB for 10MHz band and above and upper sideband USB for 7MHz in the GENERAL COVERAGE operation 9MHz band and below will be selected 4 RTTY For normal RTTY operation NARROW Pushing the FUNCTION KEY first then the RTTY switch filter is switched to the narrow CW filter when the optional 455KHz narrow CW filter is installed No sound can be heard when the optional narrow CW filter is not installed For VOX operation in SSB AM or FM adjust the control so that the VOX circuit will operate with normal speech 34 VOX DELAY VOX time constant CONTROL This controls the transmit to receive switching time Adjust it so transmit to receive switching will not occur during short pauses in normal speech 39 MULTI FUNCTION METER When in the receive mode the meter acts as an S meter regardless of the position of the meter switch Signal strength is indicated on a scale of S1 S9 and S9 to S9 60dB In the CW operation adjust this control to suit your keying speed If the control is set at the FULL completely counterclockwise position it will reach full break in CW In the transmit mode the meter has six functions which are selected by the Meter Switch 6 35 NB LEVEL CONTROL Controls the threshold level of the noise blanker Adjust the control so that incoming noises will be disappeared 40 TRANSMIT INDICATOR Illuminates when the transceiver is in the transmit mode 36 FUNCTION KEY Increases the function of the MODE SELECT switches MEMORY WRITE button FREQUENCY TRANSFER button and RIT XIT CLEAR button by pushing this key switch first 41 RECEIVE INDICATOR Illuminates when the squelch is opened in the receive mode 42 NARROW INDICATOR Illuminates when the set is on CW Narrow or RTTY Narrow mode This indicator illuminates not only when the optio nal CW filter is installed but also if it is not installed 37 FUNCTION KEY INDICATOR This indicator is lit by pushing the FUNCTION KEY to indicate the second function will be selected and turned off by pushing one of the dual function switches or buttons 8
