9 | Configuration
Installer reference guide
126
ERLA03DAV3 + EHFH03S18DJ3V
Daikin Altherma 3 R F
4P596806-1A – 2020.05
Go to setpoint mode … Set the setpoint mode to …
[A.3.1.1.1] Main > LWT setpoint
mode
Weather dep. OR WD/scheduled
Additional zone – Heating/Cooling
[A.3.1.2.1] Additional > LWT
setpoint mode
Weather dep. OR WD/scheduled
Tank
[A.4.6] Domestic hot water (DHW)
> SP mode
Weather dep.
To change the weather-dependent curve
Zone Go to …
Main zone – Heating [7.7.1.1]Main > Set weather-
dependent heating
Main zone – Cooling [7.7.1.2] Main > Set weather-
dependent cooling
Additional zone – Heating [7.7.2.1]Additional > Set
weather-dependent heating
Additional zone – Cooling [7.7.2.2] Additional > Set
weather-dependent cooling
Tank [A.4.7] Domestic hot water (DHW)
> Weather-dependent curve
INFORMATION
Maximum and minimum setpoints
You cannot configure the curve with temperatures that are higher or lower than the
set maximum and minimum setpoints for that zone or for the tank. When the
maximum or minimum setpoint is reached, the curve flattens out.
To fine-tune the weather-dependent curve
The following table describes how to fine-tune the weather-dependent curve of a
zone or tank:
You feel … Fine-tune with setpoints:
At regular outdoor
temperatures …
At cold outdoor
temperatures …
Y2
(a)
Y1
(a)
X1
(a)
X2
(a)
OK Cold ↑ — ↑ —
OK Hot ↓ — ↓ —
Cold OK — ↑ — ↑
Cold Cold ↑ ↑ ↑ ↑
Cold Hot ↓ ↑ ↓ ↑
Hot OK — ↓ — ↓
Hot Cold ↑ ↓ ↑ ↓
Hot Hot ↓ ↓ ↓ ↓
(a)
See "9.3.22-points curve"[4125].
