Philips HR7766 [10/240] Blade unit



You can use the blade unit to chop, mix, blend or puree ingredients.

1 Remove the protective cover from the blade (Fig. 8).

The cutting edges are very sharp. Do not touch them.

2 Put the blade unit on the tool holder and put the tool holder in the bowl (Fig. 9).

3 Put the ingredients in the bowl. Pre-cut large pieces of food into pieces of approx. 3 x 3 x

3cm. Put the lid on the bowl.

4 Put the pusher in the feeding tube.

5 Set the control knob to speed 2 to switch on the appliance.

- The process continues until you set the control to O.

- To process ingredients briey, turn the control knob to PULSE one or more times.



- When you chop onions, turn the control knob to PULSE a few times to prevent the onions

from becoming too nely chopped.

- Do not let the appliance run too long when you chop (hard) cheese or chocolate. Otherwise

these ingredients become too hot, start to melt and turn lumpy.

- Do not use the blade to chop very hard ingredients like coffee beans, turmeric, nutmeg and ice

cubes, as this may cause the blade to get blunt.

- The standard processing time for all chopping jobs is 30-60 seconds.

- If food sticks to the blade or to the wall of the bowl, switch off the appliance and unplug it. Then

use a spatula to remove the food from the blade or from the wall of the bowl.



Never process hard ingredients like ice cubes with the discs.

The cutting edges of the discs are very sharp. Do not touch them.

1 Put the tool holder in the bowl (Fig. 10).

2 Place the desired disc on top of the tool holder (Fig. 11).

3 Assemble the lid onto the bowl.

4 Put the ingredients in the feeding tube.

- Pre-cut large ingredients into chunks that t in the feeding tube.

- Fill the feeding tube evenly for the best results.

- When you have to process a large amount of ingredients, process small batches and empty the

bowl between batches.

5 Set the control knob to speed 1 to switch on the appliance.

- The process continues until you set the control knob to O.

6 Press the pusher lightly onto the ingredients in the feeding tube.



The adjustable slicing disc has a very sharp cutting edge. Do not touch the cutting edge.

1 Insert the slicing insert into the top of the carrier (Fig. 12).

2 Insert the knob into the bottom of the carrier (1) and turn it anticlockwise to x it

(2) (Fig. 13).

3 Turn the adjusting knob to set the slicing disc to the slicing thickness you prefer (Fig. 14).

10
