Philips HR7766 [16/240] Storage

1 To remove any meat left behind in the cutter housing, pass pieces of bread through the

cutter housing.

2 Switch off the appliance and unplug it.

3 Remove the pusher and the tray (Fig. 51).

4 Screw the screw ring anticlockwise (1) and remove it (2). Also remove the grinding disc, the

cutter unit and the worm shaft. (Fig. 52)

5 Press the release button (1), turn the cutter housing clockwise (2) and remove it from the

gear housing (3) (Fig. 53).

6 Turn the gear housing anticlockwise (1) and lift it off the motor unit (2) (Fig. 54).

7 Clean all parts that have come into contact with meat with hot water and some washing-up

liquid immediately after use (Fig. 55).

8 Rinse them with clean hot water and dry them immediately with a tea towel.

9 Lubricate the discs and the worm shaft with some vegetable oil before you store them.



The appliance comes with a pulp container that allows you to store the parts of the appliance in an

organised way.

1 Put the kneading accessory, the adjustable slicing disc and the shredding disc in the storage

box (Fig. 56).

2 Put the French fries disc in the storage box and t the balloon beater on top of the tool

holder.

3 Put the blade unit on top of the balloon beater. (Fig. 57)

4 Put the granulating disc on top of the blade unit. (Fig. 58)

5 Remove the screw cap from the motor unit and assemble the pulp container with the sieve

onto the motor unit.

Note: You can store the screw cap in the storage box or in the blender jar.

6 Place the storage box in the pulp container (Fig. 59).

7 Assemble the lid on the pulp container and insert the pusher of the juicer into the

lid (Fig. 60).

8 Wind the mains cord round the bracket on the back of the motor unit (Fig. 61).



Do not throw away the appliance with the normal household waste at the end of its life, but hand it

in at an ofcial collection point for recycling. By doing this, you help to preserve the environment.



If you need service or information or if you have a problem, please visit the Philips website at

www.philips.com or contact the Philips Consumer Care Centre in your country (you nd its phone

number in the worldwide guarantee leaet). If there is no Consumer Care Centre in your country,

go to your local Philips dealer.

16
