2MXS40H2V1B
Cooling (50Hz 230V)
Outdoor unit
Combination of
indoor unit
Capacity of each indoor unit
Each capacity (kW) Total capacity (kW) Total input (W) Total current (A) Power factor (%)
A room B room Rating (min ~ max) Rating (min ~ max) Rating (min ~ max) Rating
2MXS40H2V1B
2.0 2.00 - 2.00 1.50 ~ 2.40 440 330 ~ 570 2.0 1.5 ~ 2.6 94
2.5 2.50 - 2.50 1.50 ~ 3.00 610 330 ~ 800 2.8 1.5 ~ 3.7 94
3.5 3.50 - 3.50 1.50 ~ 4.00 1050 330 ~ 1360 4.8 1.5 ~ 6.2 95
2.0 + 2.0 2.00 2.00 4.00 1.75 ~ 4.20 1040 310 ~ 1120 4.8 1.4 ~ 5.2 94
2.0 + 2.5 1.85 2.15 4.00 1.75 ~ 4.30 1030 310 ~ 1170 4.8 1.4 ~ 5.4 94
2.0 + 3.5 1.75 2.25 4.00 1.75 ~ 4.50 1000 310 ~ 1230 4.6 1.4 ~ 5.7 94
2.5 + 2.5 2.00 2.00 4.00 1.75 ~ 4.40 1020 310 ~ 1230 4.7 1.4 ~ 5.7 94
2.5 + 3.5 1.80 2.20 4.00 1.75 ~ 4.60 990 310 ~ 1310 4.6 1.4 ~ 6.1 94
Heating (50Hz 230V)
Outdoor unit
Combination of
indoor unit
Capacity of each indoor unit
Each capacity (kW) Total capacity (kW) Total input (W) Total current (A) Power factor (%)
A room B room Rating (min ~ max) Rating (min ~ max) Rating (min ~ max) Rating
2MXS40H2V1B
2.0 3.00 - 3.00 1.10 ~ 3.70 820 260 ~ 1230 3.8 1.2 ~ 5.7 94
2.5 3.40 - 3.40 1.10 ~ 4.10 1020 260 ~ 1480 4.7 1.2 ~ 6.8 95
3.5 3.80 - 3.80 1.10 ~ 4.40 1280 260 ~ 1720 5.9 1.2 ~ 7.9 95
2.0 + 2.0 2.10 2.10 4.20 1.40 ~ 4.60 960 250 ~ 1120 4.4 1.1 ~ 5.1 95
2.0 + 2.5 2.10 2.30 4.40 1.40 ~ 4.70 1040 250 ~ 1170 4.7 1.1 ~ 5.3 96
2.0 + 3.5 2.00 2.40 4.40 1.40 ~ 4.70 1000 240 ~ 1120 4.5 1.1 ~ 5.1 96
2.5 + 2.5 2.20 2.20 4.40 1.40 ~ 4.70 1030 250 ~ 1160 4.7 1.1 ~ 5.3 96
2.5 + 3.5 2.05 2.35 4.40 1.40 ~ 4.70 990 240 ~ 1110 4.5 1.1 ~ 5.0 96
3D063422A
NOTES
1. Cooling capacity is based on 27°C DB/19°C WB (Indoor temperature), 35°C DB (Outdoor temperature).
Heating capacity is based on 20°C DB (Indoor temperature), 7°C DB/6°C WB (Outdoor temperature).
2. It’s possible to connect an indoor unit up to 6.0 kW.
3. It is impossible to connect the indoor unit for one room only.
4. The above is the value for connecting with the following indoor units.
2.0, 2.5, 3.5 kW class; Wall mounted ATXS-G, FTXS-J (NW-S2) series.
2MXS50H2V1B
Cooling (50Hz 230V)
Outdoor unit
Combination of
indoor unit
Capacity of each indoor unit
Each capacity (kW) Total capacity (kW) Total input (W) Total current (A) Power factor (%)
A room B room Rating (min ~ max) Rating (min ~ max) Rating (min ~ max) Rating
2MXS50H2V1B
2.0 2.00 - 2.00 1.60 ~ 2.60 390 330 ~ 580 1.9 1.6 ~ 2.8 91
2.5 2.50 - 2.50 1.60 ~ 3.10 560 330 ~ 800 2.7 1.6 ~ 3.8 91
3.5 3.50 - 3.50 1.60 ~ 4.00 940 320 ~ 1240 4.5 1.5 ~ 5.9 91
4.2 4.20 - 4.20 1.60 ~ 4.70 1380 320 ~ 1850 6.6 1.5 ~ 8.8 91
5.0 5.00 - 5.00 1.60 ~ 5.10 1940 320 ~ 2070 9.3 1.5 ~ 9.9 91
2.0 + 2.0 2.00 2.00 4.00 1.95 ~ 5.00 870 340 ~ 1360 4.2 1.6 ~ 6.5 91
2.0 + 2.5 2.00 2.50 4.50 1.95 ~ 5.10 1070 330 ~ 1450 5.1 1.6 ~ 6.9 91
2.0 + 3.5 1.82 3.18 5.00 1.95 ~ 5.40 1350 340 ~ 1620 6.5 1.6 ~ 7.7 91
2.0 + 4.2 1.61 3.39 5.00 1.95 ~ 5.50 1340 340 ~ 1730 6.4 1.6 ~ 8.3 91
2.0 + 5.0 1.43 3.57 5.00 1.95 ~ 5.50 1310 340 ~ 1710 6.3 1.6 ~ 8.2 91
2.5 + 2.5 2.50 2.50 5.00 1.95 ~ 5.30 1380 340 ~ 1610 6.6 1.6 ~ 7.7 91
2.5 + 3.5 2.08 2.92 5.00 1.95 ~ 5.40 1340 340 ~ 1610 6.4 1.6 ~ 7.7 91
2.5 + 4.2 1.87 3.13 5.00 1.95 ~ 5.50 1330 340 ~ 1720 6.4 1.6 ~ 8.2 91
2.5 + 5.0 1.67 3.33 5.00 1.95 ~ 5.50 1300 340 ~ 1700 6.2 1.6 ~ 8.1 91
3.5 + 3.5 2.50 2.50 5.00 1.98 ~ 5.40 1290 340 ~ 1550 6.2 1.6 ~ 7.4 91
3.5 + 4.2 2.27 2.73 5.00 1.98 ~ 5.50 1280 340 ~ 1650 6.1 1.6 ~ 7.9 91
3.5 + 5.0 2.06 2.94 5.00 1.98 ~ 5.50 1270 340 ~ 1620 6.1 1.6 ~ 7.7 91
4.2 + 4.2 2.50 2.50 5.00 1.98 ~ 5.50 1270 340 ~ 1620 6.1 1.6 ~ 7.7 91
Heating (50Hz 230V)
Outdoor unit
Combination of
indoor unit
Capacity of each indoor unit
Each capacity (kW) Total capacity (kW) Total input (W) Total current (A) Power factor (%)
A room B room Rating (min ~ max) Rating (min ~ max) Rating (min ~ max) Rating
2MXS50H2V1B
2.0 3 .00 - 3.00 1.16 ~ 3.70 780 230 ~ 1080 3.7 1.1 ~ 5.2 91
2.5 3.40 - 3.40 1.16 ~ 4.10 940 220 ~ 1270 4.5 1.1 ~ 6.1 91
3.5 4.00 - 4.00 1.16 ~ 4.60 1180 220 ~ 1460 5.6 1.1 ~ 7.0 91
4.2 4.70 - 4.70 1.16 ~ 5.10 1490 220 ~ 1730 7.1 1.1 ~ 8.3 91
5.0 5.40 - 5.40 1.28 ~ 5.60 1770 230 ~ 1910 8.5 1.1 ~ 9.1 91
2.0 + 2.0 2.65 2.65 5.30 1.18 ~ 5.70 1260 220 ~ 1400 6.0 1.1 ~ 6.7 91
2.0 + 2.5 2.44 3.06 5.50 1.18 ~ 5.80 1320 220 ~ 1430 6.3 1.1 ~ 6.8 91
2.0 + 3.5 2.04 3.56 5.60 1.24 ~ 5.90 1310 230 ~ 1390 6.3 1.1 ~ 6.6 91
2.0 + 4.2 1.84 3.86 5.70 1.25 ~ 6.00 1340 230 ~ 1440 6.4 1.1 ~ 6.9 91
2.0 + 5.0 1.63 4.07 5.70 1.29 ~ 6.20 1330 230 ~ 1480 6.4 1.1 ~ 7.1 91
2.5 + 2.5 2.80 2.80 5.60 1.18 ~ 5.80 1380 220 ~ 1430 6.6 1.1 ~ 6.8 91
2.5 + 3.5 2.38 3.32 5.70 1.24 ~ 6.00 1340 230 ~ 1450 6.4 1.1 ~ 6.9 91
2.5 + 4.2 2.13 3.57 5.70 1.25 ~ 6.10 1330 230 ~ 1470 6.4 1.1 ~ 7.0 91
2.5 + 5.0 1.90 3.80 5.70 1.35 ~ 6.30 1320 230 ~ 1520 6.3 1.1 ~ 7.3 91
3.5 + 3.5 2.85 2.85 5.70 1.30 ~ 6.10 1330 230 ~ 1460 6.4 1.1 ~ 7.0 91
3.5 + 4.2 2.59 3.11 5.70 1.31 ~ 6.20 1320 230 ~ 1480 6.3 1.1 ~ 7.1 91
3.5 + 5.0 2.35 3.35 5.70 1.35 ~ 6.40 1310 230 ~ 1560 6.3 1.1 ~ 7.5 91
4.2 + 4.2 2.85 2.85 5.70 1.32 ~ 6.30 1310 230 ~ 1500 6.3 1.1 ~ 7.2 91
3D063424A
NOTES
1. Cooling capacity is based on 27°C DB/19°C WB (Indoor temperature), 35°C DB (Outdoor temperature).
Heating capacity is based on 20°C DB (Indoor temperature), 7°C DB/6°C WB (Outdoor temperature).
2.
It’s possible to connect an indoor unit up to 8.5 kW.
3. It is impossible to connect the indoor unit for one room only.
4. The above is the value for connecting with the following indoor units.
2.0, 2.5, 3.5, 4.2, 5.0 kW class; Wall mounted ATXS-G, FTXS-J (NW-S2) series.
