4 Capacity tables
4 - 3 Cooling Capacity Tables
2MXS50
★ Cooling (50Hz 230V)
3D059192
Combination
(Capacity)
outdoor
air temp.
Indoor air temp.: °CWB
14.0°C 16.0°C 18.0°C 19.0°C 22.0°C 24.0°C
TC PI TC PI TC PI TC PI TC PI TC PI
°CDBkWkWkWkWkWkWkWkWkWkWkWkW
2.0 10.0 2.91 0.50 3.03 0.51 3.15 0.52 3.21 0.52 3.38 0.54 3.50 0.55
12.0 2.86 0.51 2.98 0.52 3.10 0.53 3.16 0.53 3.34 0.55 3.46 0.56
15.0 2.78 0.52 2.90 0.53 3.02 0.55 3.08 0.55 3.26 0.57 3.38 0.58
18.0 2.71 0.54 2.83 0.55 2.95 0.56 3.01 0.57 3.19 0.59 3.31 0.60
20.0 2.66 0.55 2.78 0.57 2.90 0.58 2.96 0.58 3.14 0.60 3.26 0.61
22.0 2.62 0.57 2.74 0.58 2.85 0.59 2.91 0.59 3.09 0.61 3.21 0.62
25.0 2.54 0.59 2.66 0.60 2.78 0.61 2.84 0.62 3.02 0.63 3.14 0.64
28.0 2.47 0.61 2.59 0.62 2.71 0.63 2.77 0.64 2.95 0.65 3.07 0.66
32.0 2.37 0.64 2.49 0.65 2.61 0.66 2.67 0.67 2.85 0.68 2.97 0.69
35.0 2.30 0.66 2.42 0.67 2.54 0.69 2.60 0.69 2.78 0.71 2.90 0.72
40.0 2.18 0.71 2.30 0.72 2.42 0.73 2.48 0.73 2.66 0.75 2.78 0.76
43.0 2.11 0.73 2.23 0.74 2.35 0.75 2.41 0.76 2.59 0.78 2.71 0.79
46.0 2.03 0.76 2.15 0.77 2.27 0.78 2.33 0.79 2.51 0.80 2.63 0.82
2.5 10.0 3.22 0.60 3.61 0.68 3.75 0.69 3.82 0.70 4.04 0.72 4.18 0.74
12.0 3.22 0.63 3.55 0.69 3.69 0.71 3.76 0.71 3.98 0.73 4.12 0.75
15.0 3.22 0.67 3.46 0.71 3.61 0.73 3.68 0.74 3.89 0.76 4.03 0.77
18.0 3.22 0.72 3.38 0.74 3.52 0.75 3.59 0.76 3.81 0.78 3.95 0.80
20.0 3.18 0.74 3.32 0.75 3.46 0.77 3.53 0.78 3.75 0.80 3.89 0.81
22,0 3.12 0.76 3.26 0.77 3.40 0.79 3.48 0.79 3.69 0.81 3.83 0.83
25.0 3.03 0.78 3.17 0.80 3.32 0.81 3.39 0.82 3.60 0.84 3.75 0.86
28.0 2.95 0.81 3.09 0.83 3.23 0.84 3.30 0.85 3.52 0.87 3.66 0.89
32.0 2.83 0.85 2.97 0.87 3.12 0.88 3.19 0.89 3.40 0.91 3.54 0.93
35.0 2.74 0.88 2.89 0.90 3.03 0.91 3.10 0.92 3.31 0.94 3.46 0.96
40.0 2.60 0.94 2.74 0.96 2.88 0.97 2.96 0.98 3.17 1.00 3.31 1.01
43.0 2.51 0.98 2.65 0.99 2.80 1.01 2.87 1.01 3.08 1.04 3.23 1.05
46.0 2.43 1.01 2.57 1.03 2.71 1.04 2.78 1.05 3.00 1.07 3.14 1.09
3.5 10.0 3.29 0.67 4.04 0.86 4.84 1.07 4.93 1.08 5.21 1.11 5.39 1.14
12.0 3.29 0.70 4.04 0.89 4.76 1.09 4.86 1.10 5.13 1.13 5.32 1.16
15.0 3.29 0.75 4.04 0.95 4.65 1.12 4.75 1.13 5.02 1.17 5.21 1.19
18.0 3.29 0.80 4.04 1.02 4.54 1.16 4.63 1.17 4.91 1.21 5.09 1.23
20.0 3.29 0.84 4.04 1.07 4.47 1.19 4.56 1.20 4.84 1.23 5.02 1.25
22.0 3.29 0.88 4.04 1.12 4.39 1.21 4.48 1.22 4.76 1.26 4.94 1.28
25.0 3.29 0.94 4.04 1.21 4.28 1.25 4.37 1.27 4.65 1.30 4.83 1.32
28.0 3.29 1.01 3.98 1.28 4.17 1.30 4.26 1.31 4.54 1.34 4.72 1.37
32.0 3.29 1.12 3.84 1.34 4.02 1.36 4.11 1.37 4.39 1.41 4.57 1.43
35.0 3.29 1.22 3.72 1.39 3.91 1.41 4.00 1.42 4.28 1.46 4.46 1.48
40.0 3.29 1.41 3.54 1.47 3.72 1.50 3.81 1.51 4.09 1.54 4.27 1.57
43.0 3.24 1.51 3.43 1.53 3.61 1.55 3.70 1.56 3.98 1.60 4.16 1.62
46.0 3.13 1.56 3.31 1.59 3.50 1.61 3.59 1.62 3.87 1.66 4.05 1.68
Combination
(Capacity)
outdoor
air temp.
Indoor air temp.: °CWB
14.0°C 16.0°C 18.0°C 19.0°C 22.0°C 24.0°C
TC PI TC PI TC PI TC PI TC PI TC PI
°CDBkWkWkWkWkWkWkWkWkWkWkWkW
4.2 10.0 3.29 0.67 4.04 0.86 4.85 1.20 5.28 1.34 6.12 1.61 6.34 1.64
12.0 3.29 0.70 4.04 0.89 4.85 1.25 5.28 1.40 6.03 1.64 6.25 1.67
15.0 3.29 0.75 4.04 0.95 4.85 1.33 5.28 1.49 5.90 1.69 6.12 1.72
18.0 3.29 0.80 4.04 1.02 4.85 1.43 5.28 1.60 5.77 1.74 5.99 1.77
20.0 3.29 0.84 4.04 1.07 4.85 1.50 5.28 1.68 5.68 1.78 5.90 1.81
22.0 3.29 0.88 4.04 1.12 4.85 1.58 5.27 1.77 5.59 1.82 5.81 1.85
25.0 3.29 0.94 4.04 1.21 4.85 1.70 5.14 1.83 5.46 1.88 5.68 1.91
28.0 3.29 1.01 4.04 1.44 4.85 1.84 5.01 1.89 5.33 1.94 5.55 1.97
32.0 3.29 1.12 4.04 1.60 4.72 1.96 4.83 1.98 5.16 2.03 5.37 2.06
35.0 3.29 1.22 4.04 1.74 4.59 2.04 4.70 2.05 5.02 2.10 5.24 2.13
40.0 3.29 1.41 4.04 2.02 4.37 2.16 4.48 2.18 4.81 2.23 5.01 2.25
43.0 3.29 1.67 4.03 2.21 4.24 2.24 4.35 2.25 4.64 2.25 4.82 2.25
46.0 3.29 1.84 3.88 2.55 4.08 2.25 4.18 2.25 4.47 2.25 4.65 2.25
5.0 10.0 4.00 0.91 4.91 1.18 5.89 1.51 6.29 1.65 6.64 1.70 6.87 1.73
12.0 4.00 0.95 4.91 1.23 5.89 1.58 6.19 1.68 6.54 1.73 6.78 1.77
15.0 4.00 1.01 4.91 1.32 5.89 1.69 6.05 1.73 6.40 1.79 6.64 1.82
18.0 4.00 1.08 4.91 1.41 5.79 1.77 5.91 1.79 6.26 1.84 6.49 1.88
20.0 4.00 1.13 4.91 1.48 5.69 1.81 5.81 1.83 6.16 1.88 6.40 1.92
22.0 4.00 1.19 4.91 1.56 5.60 1.85 5.72 1.87 6.07 1.92 6.30 1.96
25.0 4.00 1.28 4.91 1.69 5.46 1.92 5.57 1.93 5.93 1.99 6.16 2.02
28.0 4.00 1.38 4.91 1.83 5.31 1.98 5.43 2.00 5.78 2.05 6.02 2.09
32.0 4.00 1.54 4.89 2.04 5.12 2.08 5.24 2.10 5.59 2.15 5.83 2.18
35.0 4.00 1.68 4.75 2.12 4.98 2.15 5.10 2.17 5.45 2.22 5.68 2.25
40.0 4.00 1.95 4.51 2.25 4.72 2.25 4.82 2.25 5.12 2.25 5.32 2.25
43.0 4.00 2.16 4.32 2.25 4.53 2.25 4.63 2.25 4.93 2.25 5.13 2.25
46.0 3.94 2.25 4.16 2.25 4.36 2.25 4.46 2.25 4.76 2.25 4.96 2.25
2.0+2.0 10.0 5.48 1.10 5.70 1.13 5.93 1.15 6.04 1.16 6.38 1.20 6.61 1.25
12.0 5.39 1.12 5.61 1.15 5.84 1.17 5.95 1.19 6.29 1.22 6.51 1.25
15.0 5.25 1.16 5.47 1.19 5.70 1.21 5.81 1.22 6.15 1.26 6.38 1.28
18.0 5.11 1.20 5.34 1.23 5.56 1.25 5.68 1.26 6.01 1.30 6.24 1.32
20.0 5.02 1.23 5.25 1.25 5.47 1.28 5.58 1.29 5.92 1.33 6.15 1.35
22.0 4.93 1.26 5.15 1.28 5.38 1.31 5.49 1.32 5.83 1.36 6.06 1.38
25.0 4.79 1.30 5.02 1.33 5.24 1.35 5.36 1.36 5.69 1.40 5.92 1.42
28.0 4.66 1.35 4.88 1.37 5.11 1.40 5.22 1.41 5.56 1.45 5.78 1.47
32.0 4.47 1.42 4.70 1.44 4.92 1.47 5.04 1.48 5.38 1.52 5.60 1.54
35.0 4.34 1.47 4.56 1.49 4.79 1.52 4.90 1.53 5.24 1.57 5.46 1.59
40.0 4.11 1.56 4.33 1.59 4.56 1.61 4.67 1.63 5.01 1.66 5.24 1.69
43.0 3.97 1.62 4.20 1.65 4.42 1.67 4.53 1.69 4.87 1.72 5.10 1.75
46.0 3.83 1.69 4.06 1.71 4.29 1.73 4.40 1.75 4.74 1.78 4.96 1.81
SYMBOLS
TC: Total capacity (kW)
PI: Power input (kW)
NOTES
1 Capacities are based on the following conditions.
Corresponding refrigerant piping length: 5m
Level difference: 0m
2 The bold line is indicated the standard condition.
3 The above is the value for connecting with the following indoor units.
2.0, 2.5, 3.5, 4.2, 5.0 kW Class; wall mounted series.
H
H
